Precision planetary gearbox is a new-generation product developed by our company, which integrates advanced technologies at home and abroad, its main features are as follows:
1. Low Noise: Average under 67 dB.
2. Low Backlash: Backlash is less than 10 arcmin for a single stage. Less than 12 arcmin for two stages.
3 . High Efficiency: Above 96% for single stage, above 94% for two stages.
4. High Input Speed: up to 3500 RPM.
5 . High Torque: Higher torque output than conventional standard planetary gearboxes.
6. High Stability: Employs high tensile strength alloy steel. Gear hardening is made for the entire gear instead of only surface hardening,
which extends gear service life and maintains high accuracy as new after a long period of operation.
7 . High Reduction Ratio: with modular design. The planetary gearboxes can be interconnected, and the speed reduction ratio could be over 1/1000.
Precision Planetary Gear Reducer is widely used in the fields：
1. Aerospace, military industry.
2. Medical health, the electronic information technology industry.
3. Industrial robots, Production automation, CNC machine tool manufacturing industry.
4. Motor, textile, printing, food, metallurgical, environmental protection engineering, and warehouse logistics industry.
